Save Time & Money With This Welder!:
The WeldForce WF-205MST 200 Amp Mig Stick & Tig Digital Synergic Welder is not your standard portable multi-function MIG. Boasting 200A @ 30% output, this unit has the grunt and an impressive range of features to get the job done and save time and money. Work in manual mode, or synergic (select the material and thickness, and the machine takes care of the settings). PFC technology means the WF-205MST is incredibly power efficient, giving it more duty cycle and making it an excellent choice for use on long extension leads (up to 100m) and/or use on generators. Stick/MMA & lift-TIG capability, job save & recall, geared drive system, fan-on-demand to reduce dust intake, spool gun ready, advanced Stick and TIG functions... and too many other features to list here! Comes with 4m heavy-duty Euro-fit MIG torch, 2-stage gas-saving regulator, 0.8/0.9mm drive rollers for gas, gasless & aluminium wire, 4m earth and stick leads, 15A plug fitted, cable strap, and large carry bag. Maximum recommended MIG welding capacity of 10mm (mild steel).
Includes::
- Cable Retaining Strap
- Driver Roller for 0.8/0.9mm gasless wire
- Driver Roller for 0.8/0.9mm steel/solid wire
- Driver Roller for 1.0/1.2mm aluminium wire
- Earth Lead 4m
- Gas Regulator
- Large Carry Bag
- Long Power Lead 3m
- MIG Torch H/Duty BZL 25 4m
- Stick Lead 4m

Features & Benefits::
- 200A @ 30% max MIG output
- Weld up to 10mm Mild Steel (max MIG capacity)
- Standard: AS 60974.1
- Fitted with 15A 240V plug
- Power Factor Correction (PFC) - reduced power draw, increased duty-cycle, ideal for long leads & generators
- Manual or Synergic (enter material type & thickness and machine will set parameters automatically)
- 20+ Pre-set Programs - for different materials
- Job Save - store custom settings for up to 20 jobs
- Geared Wire Drive System
- Takes 1kg (D100mm) or 5kg (D200mm) spools
- Spool Gun Ready
- Generator Friendly - min 8kva, ideal 10+kva
- Fan-on-Demand - reduces dust intake
- Stressed-Tested - to 440V & over-specified componentry for reliability
- Shipping Weight: 17kg

Welding Current / Voltage Output: 40A/16V - 200A/24V
Duty Cycle (40 C): 200A @ 30%
Wire Sizes / Capacity: 0.6, 0.8, 0.9, 1.0mm
Welding Current Output: 10 – 200A
Duty Cycle: 200A @ 25%
MMA Electrode Size / Capacity: 1.6 – 4.0mm
Welding Current Output: 10 – 200A
Duty Cycle: 200A @ 35%
TIG Tungsten Electrode Size / Capacity: 1.6 - 2.4mm
Dimensions::
- L550 x W215 x H415mm
- Weight: 17kg
Warranty:
- 7 Year Warranty (if registered within 30 days of purchase)
